G3/4" Male Thread Brass Water Flow Sensor Switch, Hall Effect Liquid Flowmeter Fluidmeter Counter, 1-30L/Min
SKU: PGABL1217579
VENDOR: GREDIA
You Save: $3.80 (13%)
Hurry! Only 10 Left in Stock!
Free Shipping Across the United States
All orders within the United States qualify for 100% free shipping.
Fast Processing & Dispatch
All orders are shipped within 1 business day after purchase.
30-Day Free Returns
Not satisfied? You can return your order for free within 30 days after delivery.
G3/4" Male Thread Brass Water Flow Sensor Switch Hall Effect Liquid Flowmeter Fluidmeter Counter BSP 1-30L/Min(60mm in Total Length)
G3/4" Male Thread Brass Water Flow Sensor Switch, Hall Effect Liquid Flowmeter Fluidmeter Counter, 1-30L/Min
Water flow sensor is mainly composed of plastic valve body, water flow rotor assembly and Hall sensor. It is installed at the inlet end of the water heater to detect the inlet water flow. When the water passes through the water flow rotor assembly, the magnetic rotor rotates and the speed changes with the flow rate change. The Hall sensor outputs the corresponding pulse signal and feeds it back to the controller, which is controlled by the control. The device determines the size of the water flow and regulates it. Features 1.The appearance of this product is light and handy, small in size, easy to install. 2.The stainless steel beads are set inside the impeller, which is always wear-resistant. 3. The high-quality brass with a content of more than 57% is resistant to temperature, pressure and aging, and the screw connection is tighter. 4. The imported Hall element is adopted, and the circuit is separated from the water. 5. All raw materials comply with ROHS testing standards. Specification Connection size: G3/4 inch BSPT male thread Flow range:1-30L/min Water Pressure: =1.75Mpa Working voltage range: DC5~15V F = (6.6* Q) ± 3%, Q=L/Min, error: ± 3% Working liquid temperature range: 0-80? (0-176°F) Total length:60mm Screw length: 11mm Male diameter: 25mm Note: 1. If the water quality is too poor, please add a filter at the water inlet. 2. Do not use it beyond the flow range. 3. Severe impact and chemical attack are strictly prohibited. 4. The liquid temperature should not exceed 120 degrees. 5. Install in the direction of the installation arrow on the product. Package: 1 x G3/4 inch BSPT male thread brass water flow meter switch
Key Features
- ✅ Connection size: G3/4 inch BSPT male thread, 60mm, hall effect
- ✅ Flow range: 1-30L/Min, Water Pressure: =1.75Mpa, Working voltage range: DC5~15V
- ✅ F = (6.6* Q) ± 3%, Q=L/Min, error: ± 3%, Operating temperature range: 0-80? (0-176°F)
- ✅ Material: High quality brass with more than 57% , anti-oxidation, more wear-resistant
- ✅ Wide range of applications, mainly used for water heaters, water dispensers, etc.
