HangTon HE29 24 pin 5A 250V Power Connector, Waterproof IP68 Circular Male Female Plug Panel Socket 18AWG Wire

HangTon HE29 24 pin 5A 250V Power Connector Waterproof IP68 Circular Male Female Plug Panel Socket 18AWG Wire

HangTon HE29 24 pin 5A 250V Power Connector, Waterproof IP68 Circular Male Female Plug Panel Socket 18AWG Wire

Features: In the harsh environment can provide a safe and reliable connection. HE29(Threaded Coupling) connector is ideal for any equipment for watertight, indoor / outdoor applications, such as outdoor electric tools or appliances, medical device, communications, Marine equipment, under water equipment, outdoor led lighting, outdoor LED panels, solar energy system, outdoor security cameras, transformer, control box, machines and equipment, packing machines, for data and power. Specifications: HE29: Model: 2-26 Pin Material: Plastic IP Rating: IP68 Panel Cutout Diameter: 29mm Cable Outer Diameter Range:12-15mm Coupling Type: Threaded Coupling Shell: Thermoplastic Nylon66, Fire Resistance: V-0 Insert Material: Thermoplastic PPS max temperature 260? Contact Material: Brass with Gold Plating Termination: Solder Mating Cycle: >500 times Temperature Range: -40~+100? Humidity: +40? 95±3% Vibrator: 10~500Hz, acceleration 100m/s² Shock: 40~80times/min, acceleration 250m/s² Package Includes: 1 x Cable Plug with Male Pins 1 x Chassis Socket 1 x Waterproof / Dustproof Cap

Key Features

• ✅ Cable outer diameter range: 12-15mm, Wire Size: =0.75mm² or 18AWG, Contact Diameter: F1mm
• ✅ Rated Voltage/Current : AC 250V/5A, Resistance: 5mO
• ✅ For indoor and outdoor use. Protected against solids & liquids, provide a secure and reliable connection in the harsh environment.
• ✅ Straight 24-pin plug, flange panel mount socket with 4 screws.
• ✅ Plastic, waterproof IP68, threaded coupling, panel mount, quick disconnect, solder plug & socket
