PZEM-003 DC Power Meter, Voltage, Current, Power Consumption Analyzer with USB to 485 Module

PZEM-003 DC Voltage, Current, Power Consumption, Power Meter, Power Analyzer, DC AMP Meter, Power Meter Communication Module (PZEM-003 + USB to 485 Module)

PZEM-003 DC Power Meter, Voltage, Current, Power Consumption Analyzer with USB to 485 Module

Key Features

• ✅ Main uses: For measuring DC voltage, current, active power, frequency and energy consumption.
• ✅ Built-in shunt: The current measurement range is 0.01-10A.
• ✅ Physical layer: Using UART to RS485 communication interface, Porter rate of 9600, data bit 8, stop bit 2, no parity.
• ✅ Application layer: Communicate using the ModbusRTU protocol, which only supports function codes such as 0x03, 0x04, 0x06, 0x41, 0x42, etc.
• ✅ Voltage threshold: divided into high voltage and low voltage thresholds, when the measured voltage exceeds the threshold, it can be alarmed.

✅ Product Dimensions: 3.54 x 2.4 x 0.98 inches; 2.47 ounces
