Taidacent Laser Ranging Sensor Module, Non-contact Switch for Smart Robot Obstacle Avoidance, Infrared Alarm

Taidacent Laser Ranging Sensor Module Laser Diffuse Reflection Smart Non-contact Switch Smart Robot Obstacle Avoidance Motion Detection Infrared Switch Alarm (NPN Output)

Taidacent Laser Ranging Sensor Module, Non-contact Switch for Smart Robot Obstacle Avoidance, Infrared Alarm

Features 1. Strong anti-interference ability 2. Intelligent induction non-contact switch, safe and hygienic 3. Small sensing angle 4. Small size, easy to install 5. Multiple ways to output, easy to use 6. Not affected by the color of the surface of the object 7. In indoor environment, real-time measurement distance up to 4 meters 8. Multi-layer filter cover, more stable induction Application Scope 1. Intelligent induction sanitary ware. 2. Home security. 3. Intelligent detection, intelligent control. 4. Robot obstacle recognition. 5. Real-time display distance. 6. Faucet sensor, automatic flushing of urinal, automatic hand dryer, anti-theft device, automatic doorbell, stair aisle sensor, TV close-up TV reminder, automatic door, advertising light box, automatic trash can. Working voltage DC 5~24V Sensing distance: Within the effective distance (10mm~4000mm), the calibration test is performed in various modes, and various performances should meet the requirements, and the distance of 1000mm can be measured in the sun. Induction accuracy ±4% 940 nm Laser Transmitter Sensing angle 35 degrees for transmit, 25 degrees for receive. Short Circuit Protection Output is shut down when more than 1A Specification 24*24 (main shell) Load current 300mA Operating current 15mA Working environment temperature -20~70? Storage temperature -20~85? Cable length 30cm (±10MM) Material: Filter: PC Optical Material, Shell: PC-V0 Fire Resistant Output mode UART serial port, NPN, high and low level

Key Features

• ✅ Waterproof IP67 industrial grade laser sensor with OTF optical lens.
• ✅ Laser ranging sensor with high precision, small size and long range
• ✅ Threaded concealed fixing is more convenient
• ✅ Smart non-contact switch, laser ranging sensor with UART serial port, high and low level or NPN drive output.
• ✅ The sensor uses the principle of diffuse reflection of laser light on objects: when a person or object enters the sensing area set by the sensor, the sensor outputs a signal and can accurately output the distance; when the person or object leaves the sensing area, the sensor turns off the output.

✅ Product Dimensions: 0.94 x 0.87 x 0.63 inches
